| Weight | 0.012 KG / psc. |
| Commodity number | 85389099 |
| Country of origin | CZ |
| Dimensions (WxHxD) | 10x45x39.5 mm |
| EAN code | 3471523131224 |
| Product group | SB |
| cn8 | 8538 90 99 |
| eclass | V11.0 : 27371302 |
| etim 7 | EC000041 - Auxiliary contact block |
| etim 8 | EC000041 - Auxiliary contact block |
| unspsc | 39121500 |
| rohs status | Following EU Directive 2011/65/EU |
| suitable for | |
| mounting type | Front mounting |
| terminal type | Push-in Spring Terminals |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| cb certificate | https://library.abb.com/d/CB_SE-93052A1 |
| gl certificate | https://library.abb.com/d/DNV-GL_TAE00001BV-3 |
| weee b2c / b2b | Business To Business |
| abs certificate | https://library.abb.com/d/ABS_20-2060694-PDA |
| cqc certificate | https://library.abb.com/d/CQC2011010304496319, https://library.abb.com/d/CQC2013010304651497, https://library.abb.com/d/CQC2019010304264779 |
| cul certificate | https://library.abb.com/d/UL_20180227_E252354_3_1 |
| dnv certificate | https://library.abb.com/d/DNV-GL_TAE00001BV-3 |
| rmrs certificate | https://library.abb.com/d/RMRS_1802703280 |
| rohs information | https://library.abb.com/d/1SBD250007U1000 |
| e-number (sweden) | 3210644 |
| pilot duty ul/csa | A600Q600 |
| dnv gl certificate | https://library.abb.com/d/DNV-GL_TAE00001BV-3 |
| e-number (finland) | 3708030 |
| eplan catalog tree | Electrical engineering / Relays, contactors / Auxiliary block |
| rated frequency (f) | Auxiliary Circuit 50 / 60 Hz |
| degree of protection | acc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP20 |
| low coil consumption | No |
| wire stripping length | Auxiliary Circuit 10 mm |
| rated operational voltage | Auxiliary Circuit 690 V |
| mounted auxiliary contacts | 1 NO, 0 NC |
| object classification code | K |
| rated insulation voltage (ui) | acc. to IEC 60947-5-1 and VDE 0110 (Gr. C) 690 Vacc. to UL/CSA 600 V |
| declaration of conformity - ce | https://library.abb.com/d/1SBD250007U1000 |
| declaration of conformity - ccc | https://library.abb.com/d/2020980304001258, https://library.abb.com/d/2020980304001259, https://library.abb.com/d/2020980304001053 |
| number of auxiliary contacts nc | 0 |
| number of auxiliary contacts no | 1 |
| declaration of conformity - ukca | https://library.abb.com/d/1SBD250038U1000 |
| rated operational current ac-15 (ie) | (500 V) 2 A(690 V) 2 A(24 / 127 V) 6 A(220 / 240 V) 4 A(400 / 440 V) 3 A |
| rated impulse withstand voltage (uimp) | 6 kV |
| rated short-time withstand current low voltage (icw) | for 0.1 s 140 Afor 1 s 100 A |
