| Weight | 2.4 KG / psc. |
| Commodity number | 85363030 |
| Country of origin | BG |
| Dimensions (WxHxD) | 165x250x110 mm |
| EAN code | 6417019199856 |
| Product group | FA |
| eclass | V11.1 : 27371403 |
| etim 5 | EC000216 - Switch disconnector |
| etim 6 | EC000216 - Switch disconnector |
| etim 7 | EC000216 - Switch disconnector |
| etim 8 | EC000216 - Switch disconnector |
| standards | IEC 60947-1, -3 |
| power loss | at Rated Operating Conditions per Pole 4 W |
| handle type | Pistol handle |
| rohs status | Following EU Directive 2011/65/EU |
| handle color | Black |
| neutral type | No neutral terminal |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| number of poles | 3 |
| pollution degree | 3 |
| rohs information | https://library.abb.com/d/1SCC340006D2704 |
| e-number (sweden) | 3134898 |
| e-number (finland) | 3640463 |
| enclosure material | Stainless steel |
| cable cross-section | 10 ... 70 mm2 |
| mechanical drawings | https://library.abb.com/d/OTLK251611P32.stp |
| cable entry position | Up/Down |
| degree of protection | acc. to IEC 60529 IP65 |
| cable outlets per side | 2xø32.5+ø16.5 / 2xø32.5+ø16.5 |
| impact resistance rating | Housing IK09 |
| position of pe terminals | Top In - Bottom Out |
| rated operational voltage | Main Circuit 750 V |
| mounted auxiliary contacts | 1 NO, 0 NC |
| object classification code | Q |
| position of line terminals | Top In - Bottom Out |
| rated insulation voltage (ui) | acc. to IEC/EN 60664-1 750 V |
| declaration of conformity - ce | https://library.abb.com/d/1SCC340006D2704 |
| number of auxiliary contacts nc | 0 |
| number of auxiliary contacts no | 1 |
| connecting capacity main circuit | Screw Clamp 10 ... 70 mm2Screw Clamp / PE Terminal 2pc,1.5 ... 25 mm2 |
| data sheet, technical information | https://library.abb.com/d/1SCC340015C0201 |
| maximum mounted auxiliary contacts | 2 NO, 2 NC |
| conventional thermal current (ithe) | Fully Enclosed 115 A |
| rated operational power ac-23a (pe) | (380 ... 415 V) 30 kW(500 V) 30 kW(690 V) 30 kW |
| rated operational current ac-22a (ie) | (380 ... 415 V) 63 A(500 V) 63 A(690 V) 63 A |
| rated operational current ac-23a (ie) | (380 ... 415 V) 63 A(500 V) 50 A(690 V) 35 A |
| rated short-circuit making capacity (icm) | (690 V AC) 3.6 kA |
| rated short-time withstand current low voltage (icw) | for 1 s 2.5 kA |
