| Weight | 1.727 KG / psc. |
| Commodity number | 85363030 |
| Country of origin | ES |
| Dimensions (WxHxD) | 150x150x95 mm |
| EAN code | 6417019871837 |
| Product group | FA |
| eclass | V11.1 : 27371403 |
| etim 6 | EC000216 - Switch disconnector |
| etim 7 | EC000216 - Switch disconnector |
| etim 8 | EC000216 - Switch disconnector |
| standards | IEC 60947-1, -3EN12101-3:2015 |
| handle type | Selector handle |
| rohs status | Following EU Directive 2011/65/EU |
| handle color | Red / Yellow |
| neutral type | No neutral terminal |
| terminal type | Screw Terminals |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| cb certificate | https://library.abb.com/d/CB OK_25-125_YF4, https://library.abb.com/d/TC F400 OK_25-63_YF4_ |
| enclosure type | GV3 |
| number of poles | 6 |
| pollution degree | 3 |
| rohs information | https://library.abb.com/d/1SCC340075D0201 |
| e-number (sweden) | 3135528 |
| reach declaration | https://library.abb.com/d/1SCC340076D0201 |
| special functions | EMC |
| tightening torque | acc. IEC 60947-1 2 N·m |
| enclosure material | Steel sheet |
| last ordering date | 2023-03-31 All Countries |
| cable cross-section | 2.5 ... 16 mm2 |
| mechanical drawings | https://library.abb.com/d/GV3151595S25.stp |
| cable entry position | Up/Down |
| degree of protection | acc. to IEC 60529 IP65 |
| mechanical durability | 20000 |
| cable outlets per side | 2xø25.5 / 2xø25.5 |
| impact resistance rating | Housing IK10 |
| rated operational voltage | Main Circuit 500 V |
| mounted auxiliary contacts | 1 NO, 0 NC |
| object classification code | Q |
| position of line terminals | Top In - Bottom Out |
| replacement product id (new) | OKA40S6B1F400 |
| rated insulation voltage (ui) | acc. to IEC/EN 60664-1 690 V |
| declaration of conformity - ce | https://library.abb.com/d/1SCC340070D2701 |
| number of auxiliary contacts nc | 0 |
| number of auxiliary contacts no | 1 |
| connecting capacity main circuit | Screw Clamp 2.5 ... 16 mm2Screw Clamp / PE Terminal 2pc,2.5 ... 16 mm2 |
| data sheet, technical information | https://library.abb.com/d/1SCC340004B0201 |
| maximum mounted auxiliary contacts | 1 NO, 0 NC |
| conventional thermal current (ithe) | Fully Enclosed 40 A |
| rated operational power ac-23a (pe) | (380 ... 415 V) 18.5 kW(500 V) 22 kW |
| rated operational current ac-22a (ie) | (380 ... 415 V) 40 A(500 V) 40 A |
| rated operational current ac-23a (ie) | (380 ... 415 V) 35 A(500 V) 35 A |
| rated impulse withstand voltage (uimp) | 4 kV |
| rated conditional short-circuit current (inc) | 6 kA |
| rated short-time withstand current low voltage (icw) | for 1 s 0.5 kA |
