ABB

2CCE180300R0141

Product type: E480/3-KB

E480/3KB On-off switch

Description

ON-off switsch E480/3KB in grey with 80 A and 3-poles 250/400 VACDCPDC according to DIN EN 60669-1, VDE 0632 Part 1
  • Low Voltage Products and Systems
  • Modular DIN Rail Products
  • Command and Signalling Devices
  • Switch Disconnectors
Contact Person
Thomas Hoffmann
+49 305 201 4443 ext. 1
sales@zwodltd.com
Payment
Bank TransferVisaMastercardPayPal
Worldwide shipping
DHLUnited Parcel ServiceFedEx ExpressTNT ExpressDB Schenker
Additional Information
Price: Please send request
Request Lead Time: ca. 1-2 Days
Delivery Time: By Agreement
Delivery Terms: FCA Berlin
Infoindividually for each client according to INCOM TERMS 2022
  • ZWOD Vertriebs und Logistik GmbH specializes in hard-to-find parts. Please send request a quote and save on 2CCE180300R0141.
  • ZWOD Vertriebs und Logistik GmbH carries 225191 items from ABB.
Multiples Of: 1
Product Specifications
Product AttributeAttribute Value
Weight0.19 KG / psc.
Commodity number85365000
Country of originCH
Dimensions (WxHxD)44x85x70 mm
EAN code7612270932542
Product groupAR
cn885365053
eclassV11.0 : 27142301
etim 7EC001545 - Main switch for distribution board
etim 8EC001545 - Main switch for distribution board
standardsEN60669-1
power loss5.4 W
cover colorGrey
rohs statusFollowing EU Directive 2002/95/EC August 18, 2005 and amendment
switch typeOff
weee category5. Small Equipment (No External Dimension More Than 50 cm)
weee b2c / b2bBusiness To Consumer
number of poles3
rohs informationhttps://library.abb.com/d/2CCC413008D0206
input voltage typeAC
product net length68 mm
rated current (in)80 A
rated voltage (ur)Minimum 400 V
built-in depth (t2)70 mm
degree of protectionIP20
accessories availableNo
number of contacts co0
number of contacts nc0
number of contacts no3
environmental informationhttps://library.abb.com/d/2CCC441003C0201
rated operational voltage230/400 V
object classification codeQ
declaration of conformity - cehttps://library.abb.com/d/2CCY442101D0601
data sheet, technical informationhttps://library.abb.com/d/2CCC441003C0101
width in number of modular spacings2.5
rated conditional short-circuit current (inc)10 kA
rated service short-circuit breaking capacity (ics)10 kA
