ABB

2CCF019997R0001

Product type: S802S-UCB6

S802S-UCB6 High Performance MCB

Description

S802S-UCB6 2 Poles UC-B Characteristic 6A 50 kA 500 VDC High Performance Circuit Breaker HPCB
  • Low Voltage Products and Systems
  • Modular DIN Rail Products
  • High Performance Circuit Breakers HPCBs
Contact Person
Thomas Hoffmann
+49 305 201 4443 ext. 1
sales@zwodltd.com
Payment
Bank TransferVisaMastercardPayPal
Worldwide shipping
DHLUnited Parcel ServiceFedEx ExpressTNT ExpressDB Schenker
Additional Information
Price: Please send request
Request Lead Time: ca. 1-2 Days
Delivery Time: By Agreement
Delivery Terms: FCA Berlin
Infoindividually for each client according to INCOM TERMS 2022
  • ZWOD Vertriebs und Logistik GmbH specializes in hard-to-find parts. Please send request a quote and save on 2CCF019997R0001.
  • ZWOD Vertriebs und Logistik GmbH carries 225191 items from ABB.
Multiples Of: 1
Product Specifications
Product AttributeAttribute Value
Weight0.49 KG / psc.
Commodity number85362010
Country of originSwitzerland (CH)
Dimensions (WxHxD)54x95x82.5 mm
EAN code7612271500634
Product groupAF
cn885362020
eclassV11.0 : 27141901
etim 7EC000042 - Miniature circuit breaker (MCB)
etim 8EC000042 - Miniature circuit breaker (MCB)
remarksConnection from top and bottomConnecting with CU onlyIP40 in enclosure with coverCage terminal with captive screw
standardsIEC/EN 60947-2
power loss3.6 Wat Rated Operating Conditions per Pole 1.8 W
rohs statusFollowing EU Directive 2011/65/EU
terminal typeScrew Terminals
weee category5. Small Equipment (No External Dimension More Than 50 cm)
weee b2c / b2bBusiness To Business
number of poles2
actuator markingI / O
housing materialInsulation group I, RAL 7035
pollution degree2
rohs informationhttps://library.abb.com/d/9AKK107680A3903, https://library.abb.com/d/2CCC005084D0202
mounting positionAny
tightening torque3.5 N·m
input voltage typeDC
rated current (in)6 A
rated voltage (ur)acc. to IEC 60947-2 500 V DC
built-in depth (t2)82.5 mm
connecting capacityFlexible 0...50 mm2Rigid 0...70 mm2
rated frequency (f)50...60 Hz
degree of protectionacc. to IEC 60529 IP20
mounting on din railTH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
overvoltage categoryIII
accessories availableYes
energy limiting class3
ambient air temperatureOperation -25 ... +60 °CStorage -40 ... +70 °C
tripping characteristicUC-B
recommended screw driverPozidriv 2
environmental informationhttps://library.abb.com/d/2CCY413207D0203
number of protected poles2
rated operational voltageacc. to IEC 60947-2 500 V DC
object classification codeF
contact position indicationON / OFF / TRIP
rated insulation voltage (ui)acc. to IEC/EN 60664-1 1000 V
declaration of conformity - cehttps://library.abb.com/d/2CCC005084D0202
rated operational current (ie)6 A
data sheet, technical informationhttps://library.abb.com/d/2CCC413003C0208
width in number of modular spacings3
rated impulse withstand voltage (uimp)8 kV
resistance to vibrations acc. to iec 60068-2-67 - 13.2 Hz / 1mm13.2 - 100Hz / 0.7gwith load 100% x Ie
rated service short-circuit breaking capacity (ics)(500 V DC) 50 kA
rated ultimate short-circuit breaking capacity (icu)(500 V DC) 50 kA
