| Weight | 0.25 KG / psc. |
| Commodity number | 85362010 |
| Country of origin | DE |
| Dimensions (WxHxD) | 35x88x69 mm |
| EAN code | 4013614448973 |
| Product group | AC |
| cn8 | 8536 20 10 |
| eclass | V11.0 : 27141901 |
| etim 7 | EC000042 - Miniature circuit breaker (MCB) |
| etim 8 | EC000042 - Miniature circuit breaker (MCB) |
| unspsc | 39121614 |
| remarks | Please note polarity of device |
| standards | IEC/EN 60947-2 |
| power loss | 4.02 Wat Rated Operating Conditions per Pole 2.01 W |
| rohs status | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| actuator type | Toggle |
| terminal type | Screw Terminals |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| weee b2c / b2b | Business To Business |
| number of poles | 2 |
| actuator marking | I / O |
| housing material | Insulation Group I, RAL 7035 |
| options provided | Suitable for traction application |
| pollution degree | 3 |
| rohs information | https://library.abb.com/d/2CDK400602D2703 |
| actuator material | Insulation Group II, Black, Sealable |
| installation size | acc. to DIN 43880 1 |
| mounting position | Any |
| tightening torque | 2.8 N·m |
| eplan catalog tree | Electrical engineering / Protection devices / General |
| input voltage type | AC/DC |
| rated current (in) | 16 A |
| built-in depth (t2) | 69 mm |
| connecting capacity | Busbar 10 / 10 mm2Flexible with Ferrule 0.75 ... 25 mm2Flexible 0.75 ... 25 mm2Rigid 0.75 ... 35 mm2Stranded 0.75 ... 35 mm2 |
| operational voltage | Maximum (Incl. Tolerance) 462 V ACMaximum (Incl. Tolerance) 500 V DCMinimum 12 V ACMinimum 12 V DC |
| rated frequency (f) | 50 / 60 HzDC |
| screw terminal type | Failsafe Bi-directional Cylinder-lift Terminal |
| certification agency | ENIEC |
| degree of protection | IP20IPXXBEnclosure with Cover IP40 |
| electrical endurance | 1500 DC cycle20000 AC cycle |
| mechanical endurance | 20000 cycle |
| mounting on din rail | TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715 |
| overvoltage category | III |
| accessories available | Yes |
| energy limiting class | 3 |
| ambient air temperature | Operation -25 ... +55 °CStorage -40 ... +70 °C |
| dielectric test voltage | 50/60 Hz, 1 min: 2 kV |
| power supply connection | Please Note Polarity of Device |
| tripping characteristic | C |
| environmental conditions | 28 cycleswith 55 °C / 90-96 %and 25 °C / 95-100 % |
| recommended screw driver | Pozidriv 2 |
| number of protected poles | 2 |
| rated operational voltage | acc. to IEC 60898-1 440 V ACacc. to IEC 60898-1 440 V DCacc. to IEC 60947-2 440 V ACacc. to IEC 60947-2 440 V DC |
| contact position indication | ON / OFF |
| rated short-circuit capacity | (AC) 10 kA(230 V AC) 10 kA(253 V AC) 10 kA(400 V AC) 10 kA(440 V DC) 10 kA |
| rated insulation voltage (ui) | acc. to IEC/EN 60664-1 484 V |
| declaration of conformity - ce | https://library.abb.com/d/2CDK400602D2704 |
| data sheet, technical information | https://library.abb.com/d/No document needed |
| reference ambient air temperature | 30 °C |
| interrupting rating acc. to ul1077 | (440 V DC) 10 kA |
| width in number of modular spacings | 2 |
| rated impulse withstand voltage (uimp) | 4 kVat 2000 m 5 kVat Sea Level 6.2 kV |
| resistance to shock acc. to iec 60068-2-27 | 25g / 2 shocks / 13 ms |
| rated conditional short-circuit current (inc) | (230 V) 10 kA(400 V) 10 kA |
| resistance to vibrations acc. to iec 60068-2-6 | 5g, 20 cycles at 5 ... 150 ... 5 Hz with load 0.8 In |
| rated service short-circuit breaking capacity (ics) | (440 V DC) 10 kA |
| rated ultimate short-circuit breaking capacity (icu) | (230 V AC) 10 kA(400 V AC) 10 kA(440 V AC) 10 kA(440 V DC) 10 kA |
