| Weight | 0.28 KG / psc. |
| Commodity number | 85362010 |
| Country of origin | Germany (DE) |
| Dimensions (WxHxD) | 35x115x71 mm |
| EAN code | 4016779957632 |
| Product group | AB |
| cn8 | 8536 20 10 |
| eclass | V11.0 : 27141901 |
| etim 7 | EC000042 - Miniature circuit breaker (MCB) |
| etim 8 | EC000042 - Miniature circuit breaker (MCB) |
| unspsc | 39121614 |
| standards | CSA 22.2 No. 5IEC/EN 60947-2UL 489 |
| power loss | 9.8 Wat Rated Operating Conditions per Pole 4.9 W |
| rohs status | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| terminal type | Ring-Tongue Terminals |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| ul certificate | https://library.abb.com/d/2CDZ405000A0085 |
| weee b2c / b2b | Business To Business |
| csa certificate | https://library.abb.com/d/2CDZ405000A0575 |
| number of poles | 2 |
| options provided | Ring tongue |
| pollution degree | 3 |
| rohs information | https://library.abb.com/d/2CDK400616D2703 |
| eplan catalog tree | Electrical engineering / Protection devices / General |
| input voltage type | AC |
| rated current (in) | 60 A |
| built-in depth (t2) | 69 mm |
| connecting capacity | Flexible with Ferrule 0.75 ... 25 mm2Flexible 0.75 ... 25 mm2Rigid 0.75 ... 35 mm2Stranded 0.75 ... 35 mm2 |
| rated frequency (f) | 50 / 60 Hz |
| screw terminal type | Ring-Tongue Terminal with Captive Screw |
| certification agency | CSAENIECUL |
| degree of protection | IP20 |
| overvoltage category | III |
| accessories available | Yes |
| energy limiting class | 3 |
| ambient air temperature | Operation -25 ... +55 °C |
| tripping characteristic | K |
| recommended screw driver | Pozidriv 2 |
| environmental information | https://library.abb.com/d/9AKK107680A9140 |
| number of protected poles | 2 |
| rated operational voltage | acc. to IEC 60898-1 400 V ACacc. to IEC 60947-2 400 V AC |
| rated short-circuit capacity | (230 V AC) 10 kA(400 V AC) 10 kA |
| rated insulation voltage (ui) | acc. to IEC/EN 60664-1 440 V |
| declaration of conformity - ce | https://library.abb.com/d/2CDK400616D2703 |
| data sheet, technical information | https://library.abb.com/d/2CDC002184D0202 |
| interrupting rating acc. to ul489 | (240 V AC) 10 kA(96 V DC) 10 kA |
| width in number of modular spacings | 2 |
| rated impulse withstand voltage (uimp) | 4 kVat 2000 m 5 kVat Sea Level 6.2 kV |
| rated conditional short-circuit current (inc) | (230 V) 10 kA(400 V) 10 kA |
| rated service short-circuit breaking capacity (ics) | (400 V AC) 7.5 kA |
| rated ultimate short-circuit breaking capacity (icu) | (230 V AC) 10 kA(400 V AC) 15 kA |
