| Weight | 0.36 KG / psc. |
| Commodity number | 85363030 |
| Country of origin | IT |
| Dimensions (WxHxD) | 0.07x0.085x0.069 m |
| EAN code | 8012542820901 |
| Product group | AM |
| cn8 | 85363030 |
| eclass | V11.0 : 27142201 |
| etim 7 | EC000003 - Residual current circuit breaker (RCCB) |
| etim 8 | EC000003 - Residual current circuit breaker (RCCB) |
| standards | IEC/EN 61008 |
| power loss | at Rated Operating Conditions per Pole 4.4 W |
| rohs status | Following EU Directive 2011/65/EU |
| mounting type | DIN rail |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| weee b2c / b2b | Business To Consumer |
| number of poles | 4 |
| options provided | None |
| pollution degree | 2 |
| rohs information | https://library.abb.com/d/2CSC423001K2702 |
| e-number (sweden) | 2160168 |
| eplan catalog tree | Electrical engineering / Protection devices / Ground fault current circuit breaker |
| input voltage type | AC |
| rated current (in) | 63 A |
| rated voltage (ur) | 230/400 V |
| ambient temperature | -25...55 °C |
| built-in depth (t2) | 69 mm |
| connecting capacity | Busbar 10 mm2Rigid 25 ... 25 mm2Flexible 25 ... 25 mm2 |
| rated cross-section | 4 - Multi-Wired 0...25 mm21 - Solid-Core 25...25 mm2 |
| rated frequency (f) | 50 / 60 Hz |
| degree of protection | IP2X |
| electrical endurance | 10000 cycle |
| leakage current type | A |
| accessories available | Yes |
| rated residual current | 300 mA |
| ambient air temperature | Operation -25...55 °C |
| power supply connection | Arbitrary |
| operating characteristic | Instantaneous |
| type of residual current | A type |
| environmental information | https://library.abb.com/d/Refer to RoHS |
| rated operational voltage | 230 / 400 V AC |
| object classification code | F |
| position of neutral terminals | Left |
| rated insulation voltage (ui) | 500 V |
| declaration of conformity - ce | https://library.abb.com/d/9AKK106713A5602 |
| data sheet, technical information | https://library.abb.com/d/9AKK107991A8329 |
| short-circuit current rating (sccr) | 300 mA |
| width in number of modular spacings | 4 |
| rated impulse withstand voltage (uimp) | 4 kV |
| environmental product declaration - epd | https://library.abb.com/d/9AKK108467A3700 |
| resistance to shock acc. to iec 60068-2-27 | 25g / 2 shocks / 13 ms |
| rated conditional short-circuit current (inc) | 10 kA |
| resistance to vibrations acc. to iec 60068-2-6 | 0.1 mm or 1 g - 20 cycles at 5...150...5 Hz |
| rated service short-circuit breaking capacity (ics) | 1 kA |
