Weight | 0.38 KG / psc. |
Commodity number | 85363030 |
Country of origin | Italy (IT) |
Dimensions (WxHxD) | 70x85x69 mm |
EAN code | 8012542356059 |
Product group | AM |
cn8 | 85363030 |
eclass | V11.0 : 27142201 |
etim 7 | EC000003 - Residual current circuit breaker (RCCB) |
etim 8 | EC000003 - Residual current circuit breaker (RCCB) |
standards | IEC/EN 61008 |
cable size | 25 mm2 |
power loss | 15.6 W |
mounting type | on DIN rail EN 60715 (35mm) by means of mounting clip |
terminal type | Screw Terminals |
weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
accessory type | Auxiliary contact, Signal contact/auxiliary contact, Shunt trip, Undervoltage release, Overvoltage release, Motor operating device, Auto reclosing unit |
weee b2c / b2b | Business To Consumer |
impulse current | I (max, 8 / 20 μs) 3000 A |
number of poles | 4 |
options provided | Unpacked |
pollution degree | 3 |
rohs information | https://library.abb.com/d/9AKK106713A5610 |
mounting position | Any |
test voltage (ut) | 170-253 V AC |
tightening torque | 2.8 N·m |
input voltage type | AC |
rated current (in) | 63 A |
rated voltage (ur) | 230/400 V |
built-in depth (t2) | 69.5 mm |
connecting capacity | Busbar 10 mm2Flexible 1 ... 25 mm2Stranded 1 ... 25 mm2 |
delay time (τ) | 10 ms |
number of batteries | 0 |
rated cross-section | 1 - Solid-Core 1 ... 25 mm2 |
rated frequency (f) | 50 / 60 Hz |
screw terminal type | Failsafe Bi-directional Cylinder-lift Terminal |
degree of protection | Housing IPX4Terminals IP2X |
electrical endurance | 10000 cycle |
mechanical endurance | 20000 cycle |
overvoltage category | III |
accessories available | Yes |
wire stripping length | 12 mm |
rated residual current | 30 mA |
ambient air temperature | Operation -25 ... +70 °C |
dielectric test voltage | 2500 V |
environmental conditions | 28 cycleswith 55 °C / 90-96 %and 25 °C / 95-100 % |
operating characteristic | Instantaneous (APR High Immunity) |
type of residual current | B type |
rated operational voltage | 230 / 400 V AC |
object classification code | F |
position of neutral terminals | Right |
rated insulation voltage (ui) | 440 V |
declaration of conformity - ce | https://library.abb.com/d/9AKK106713A5610 |
data sheet, technical information | https://library.abb.com/d/9AKK107991A7569 |
width in number of modular spacings | 4 |
rated impulse withstand voltage (uimp) | 4 kV |
environmental product declaration - epd | https://library.abb.com/d/9AKK108467A3700 |
number of modular spacings per din rail | 4 |
resistance to shock acc. to iec 60068-2-27 | 25g 2 shocks 13 ms |
rated residual breaking capacity (iδm) | 1 kA |
rated conditional short-circuit current (inc) | 10 kA |
resistance to vibrations acc. to iec 60068-2-6 | 0.1 mm or 1 g - 20 cycles at 5...150...5 Hz |
