| Weight | 0.067 KG / psc. |
| Commodity number | 85361010 |
| Country of origin | Romania (RO) |
| Dimensions (WxHxD) | 0.018x0.085x0.064 m |
| EAN code | 8012542998822 |
| Product group | AR |
| cn8 | 85361010 |
| eclass | V11.0 : 27142121 |
| etim 7 | EC002705 - Holder for cylindrical fuse |
| etim 8 | EC002705 - Holder for cylindrical fuse |
| remarks | For use with CU only 60°C, 75°C or 90°C wire |
| fuse size | 10x38 mm |
| fuse type | class CC |
| lock type | Padlockable |
| standards | UL 4248-1UL 4248-4 |
| dimensions | 1 module |
| power loss | at Rated Operating Conditions per Pole 3 W |
| rohs status | Following EU Directive 2011/65/EU |
| sealing type | Sealing Wire |
| mounting type | DIN rail |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| ul certificate | https://library.abb.com/d/9AKK107992A1037 |
| weee b2c / b2b | Business To Consumer |
| number of poles | 1 |
| options provided | With LED |
| rohs information | https://library.abb.com/d/2CSC444011K2701 |
| tightening torque | 2-2.5 N·m |
| rated current (in) | 30 A |
| rated voltage (ur) | 600 V |
| built-in depth (t2) | 64 mm |
| connecting capacity | Stranded 1x1.5...16 mm2Stranded 2x2...5 mm2Rigid 1x1.5...25 mm2Rigid 2x5 mm2 |
| rated frequency (f) | 60 Hz |
| ampere rating ul/csa | 30 A |
| certification agency | UL |
| degree of protection | IP20 |
| material of conductor | Copper |
| ambient air temperature | Operation -5...+40 °CStorage -25...+70 °C |
| auxiliary voltage ac/dc | LED Indicator 24-1000 V AC/DC |
| recommended screw driver | Pozidriv 2 |
| tightening torque ul/csa | 18-22 in·lb |
| environmental information | https://library.abb.com/d/See RoHS Information |
| number of protected poles | 1 |
| connecting capacity ul/csa | Stranded 1x16...3 AWGStranded 2x14...10 AWGRigid 1x16...10 AWGRigid 2x10 AWG |
| object classification code | F |
| operating humidity (rhamb) | max. 90% at +20 °C50% at max. +40 °C |
| rated insulation voltage (ui) | 1+2*Un kV |
| declaration of conformity - ce | https://library.abb.com/d/2CSC444003D2701 |
| data sheet, technical information | https://library.abb.com/d/2CSC444002B0204 |
| width in number of modular spacings | 1 |
| resistance to shock acc. to iec 60068-2-27 | 15 g11 ms18 shocks |
| resistance to vibrations acc. to iec 60068-2-6 | 2 to 13 Hz x= 1 mm peak13 to 100 Hz y= 0.7 g peak |
| shock and vibration withstand acc. to iec 61373 | Category 1, Class B |
