Pilz

266815

Product type: PMI v815

Description

PMIvisu, diagnostic and operating terminal, 15.6", resolution 1920 x1080 pixel ,capacitive touchscreen, TFT, RAM 4 GB, SSD 32 GB, 2 RJ45 port 1 Gbit/s, 1 USB host 3.0, 2 USB host 2.0, 1 HDMI port, 1 VGA port, capacitor-buffered real-time clock, 12 ... 30 V DC, 38.5 W, OS Windows10 IOT, PASvisu Runtime installed and licensed, preinstalled software: PMI v8 Assistant, PASvisu Server and Client, PVIS OPC Server UA, PSS 4000 firmware (OPC Server UA).
  • Operating and monitoring
  • Operator terminals
  • PMIvisu - Visualisation system
  • PMIvisu
Contact Person
Thomas Hoffmann
+49 305 201 4443 ext. 1
sales@zwodltd.com
Payment
Bank TransferVisaMastercardPayPal
Worldwide shipping
DHLUnited Parcel ServiceFedEx ExpressTNT ExpressDB Schenker
Additional Information
Price: Please send request
Request Lead Time: ca. 1-2 Days
Delivery Time: By Agreement
Delivery Terms: FCA Berlin
Infoindividually for each client according to INCOM TERMS 2022
  • ZWOD Vertriebs und Logistik GmbH specializes in hard-to-find parts. Please send request a quote and save on 266815.
  • ZWOD Vertriebs und Logistik GmbH carries 3973 items from Pilz.
Multiples Of: 1
Product Specifications
Product AttributeAttribute Value
Weight5.803 KG / psc.
Commodity number
Country of origin
Dimensions (WxHxD)399x260x75.1 mm
EAN code
Product group7134
ram4 GB
cas no.7439-92-1 65997-18-4
approvalCE UKCA cULus Listed EAC (Eurasian)
display typeTFT
gross weight7883 g
processor typeX86
rohs directive2011/65/EU 2015/863/EU
humidity rating0... 90% at 39°C(non-condens.)
rohs conformityyes
rohs exceptionsyes
display diagonal15.6 Zoll
operating systemWindows 10 IOT
reach compliancecontains min. 1 SVHC-substance
display resolution1920 x 1080
supply voltage (v)12 - 30 V
ambient temperature0 - 50 °C
emc to standard ...EN 61000-6-2 EN 61000-6-4
type of touchscreencapacitive
display colour depth16.7 M
power consumption dc38.5 W
processor clock speed2.0 GHz
external vga interface1 x HDMI 1 x VGA
%-part of the pollutant> 0,1
acc. shock to standard115g
condensation permitted?Not permitted
real-time clock presentYes
protection type standardEN 60529
reach included substancesLead
type of supply voltage u1DC
vibration to standard ...EN 60068-2-6
ethernet transmission rate1 Gbit/s
connector type ethernet int.RJ45
storage temperature standardEN 60068-2-1/-2
climatic suitability standardEN 60068-2-78
number of ethernet interfaces2
number of usb host interfaces1 x USB 3.0 2 x USB 2.0
rohs except.s acc. to direct.7a 6a 6c 7c I
weee classifikation (08/2018)2 device/monitor > 100 cm²
