Pilz

312440

Name: 312440
Brand: Pilz
Availability: PreOrder

Product type: PSSu E S 2AI U

Datasheet

Description

PSSu, electronic module, standard, analogue inputs and outputs, 2inputs, 3 configurable voltage ranges, 0 - 10 V, single-pole, referenced toearth, - 10/0 - 10 V, dual-pole, differential input, resolution 12 Bit.

Controller
I/O systems
PSSuniversal - I/O modules
PSSuniversal - standard I/O modules

Contact Person
Thomas Hoffmann
+49 305 201 4443 ext. 1
sales@zwodltd.com

Payment

Worldwide shipping

Additional Information
Price: Please send request
Request Lead Time: ca. 1-2 Days
Delivery Time: By Agreement
Delivery Terms: FCA Berlin individually for each client according to INCOM TERMS 2022

ZWOD Vertriebs und Logistik GmbH specializes in hard-to-find parts. Please send request a quote and save on 312440.
ZWOD Vertriebs und Logistik GmbH carries 3973 items from Pilz.

Multiples Of: 1

Product Specifications

Product Attribute	Attribute Value
Weight	0.035 KG / psc.
Commodity number	85389091
Country of origin	DE
Dimensions (WxHxD)	12.6x76x60.2 mm
EAN code
Product group	7017
approval	CE cULus Listed TÜV
etim version	ETIM-7.0
gross weight	44
eclass version	ECLASS-9.1
terminal style	plug-in
humidity rating	93 % r. h. at 40 °C
reach compliance	contains min. 1 SVHC-substance
application range	Standard
ambient temperature	0 60
emc to standard ...	EN 61000-4-4 EN 61000-6-2 EN 61000-4-5 EN 61000-6-4 EN 61000-4-6 EN 61000-4-2 EN 61000-4-3
etim reference group	EG000024
overvoltage category	II
type of input filter	RC filter
housing material code	PA
name of coding element	D
acc. shock to standard1	15g
condensation permitted?	Not permitted
type of analogue inputs	Voltage
colour of coding element	Dark grey
eclass reference feature	27242601
protection type standard	EN 60529
number of analogue inputs	2
signal range analog input	0 .. 10V (differential input) 0 .. 10V (single-ended) -10.. 10V (differential input)
vibration to standard ...	EN 60068-2-6
analog input signal type 1	Single-ended
analog input signal type 2	Differential input
analog input signal type 3	Differential input
perm. operating height asl	2000 m
potential isolation inputs	yes
analog input signal range 1	0 - 10 V
analog input signal range 2	0 - 10 V
analog input signal range 3	-10 - 10 V
climatic suitability to ...	EN 60068-2-30 EN 60068-2-2 EN 60068-2-1 EN 60068-2-78 EN 60068-2-14
pot. isolation analog inp./	Yes
ambient temperature standard	EN 60068-2-14
conversion method analog i/p	Successive approximation
housing material front plate	PC
storage temperature standard	EN 60068-2-1/-2
clearance & creepage dist. to	EN 60664-1
climatic suitability standard	EN 60068-2-30 EN 60068-2-78
resolution of analogue inputs	12
weee classifikation (08/2018)	5 devices (feed size < 50cm)
housing material lower section	PC
pollution degree clear.&creep.	2
