| Weight | 0.035 KG / psc. |
| Commodity number | 85389091 |
| Country of origin | DE |
| Dimensions (WxHxD) | 12.6x76x60.2 mm |
| EAN code | |
| Product group | 7017 |
| approval | CE cULus Listed TÜV |
| etim version | ETIM-7.0 |
| gross weight | 44 |
| eclass version | ECLASS-9.1 |
| humidity rating | 93 % r. h. at 40 °C |
| reach compliance | contains min. 1 SVHC-substance |
| application range | Standard |
| ambient temperature | 0 60 |
| emc to standard ... | EN 61131-2 EN 61000-4-4 EN 61000-4-5 EN 61000-4-6 EN 61000-4-2 EN 61000-4-3 |
| etim reference group | EG000024 |
| overvoltage category | II |
| type of input filter | Digital filter |
| housing material code | PA |
| name of coding element | H |
| acc. shock to standard1 | 15g |
| condensation permitted? | Not permitted |
| type of analogue inputs | Thermocouple |
| colour of coding element | Dark grey |
| eclass reference feature | 27242601 |
| protection type standard | EN 60529 |
| damping of input filter 1 | 90 dB (60 Hz) |
| number of analogue inputs | 2 |
| signal range analog input | Type N Type R Type B Type S Type T Type E Voltage Type J Type K |
| vibration to standard ... | EN 60068-2-6 |
| analog input signal type 1 | Type R |
| analog input signal type 2 | Type S |
| analog input signal type 3 | Type B |
| analog input signal type 4 | Type J |
| analog input signal type 5 | Type T |
| analog input signal type 6 | Type E |
| analog input signal type 7 | Type K |
| analog input signal type 8 | Type N |
| analog input signal type 9 | Voltage |
| perm. operating height asl | 2000 m |
| potential isolation inputs | yes |
| analog input signal range 1 | -50 - 1768 °C |
| analog input signal range 2 | -50 - 1768 °C |
| analog input signal range 3 | 600 - 1820 °C |
| analog input signal range 4 | -210 - 1200 °C |
| analog input signal range 5 | -200 - 400 °C |
| analog input signal range 6 | -200 - 1000 °C |
| analog input signal range 7 | -200 - 1372 °C |
| analog input signal range 8 | -200 - 1300 °C |
| analog input signal range 9 | +/-30 mV |
| analog input signal type 10 | Voltage |
| analog input signal type 11 | Voltage |
| climatic suitability to ... | EN 60068-2-30 EN 60068-2-2 EN 60068-2-1 EN 60068-2-78 EN 60068-2-14 |
| pot. isolation analog inp./ | Yes |
| ambient temperature standard | EN 60068-2-14 |
| analog input signal range 10 | +/-60 mV |
| analog input signal range 11 | +/-120 mV |
| conversion method analog i/p | Delta sigma |
| housing material front plate | PC |
| storage temperature standard | EN 60068-2-1/-2 |
| value least signif. bit u-me | 2 µV (+/-60 mV) 4 µV (+/-120 mV) 1 µV (+/-30 mV) |
| clearance & creepage dist. to | EN 60664-1 EN 61131-2 |
| climatic suitability standard | EN 60068-2-30 EN 60068-2-78 |
| weee classifikation (08/2018) | 5 devices (feed size < 50cm) |
| housing material lower section | PC |
| pollution degree clear.&creep. | 2 |
