| Weight | 0.053 KG / psc. |
| Commodity number | 85044090 |
| Country of origin | DE |
| Dimensions (WxHxD) | 25.2x76x60.2 mm |
| EAN code | |
| Product group | 7017 |
| approval | CE UKCA TÜV EAC (Eurasian) |
| etim version | ETIM-7.0 |
| gross weight | 62 |
| purpose of u1 | Module Supply |
| purpose of u2 | Periphery Supply |
| eclass version | ECLASS-9.1 |
| terminal style | steckbar |
| tolerance of u2 | -30 %/+25 % |
| purpose of uint1 | int. Systemspannung |
| reach compliance | contains min. 1 SVHC-substance |
| application range | Standard/Fail-safe |
| supply voltage (v) | 24 |
| tolerance of uint1 | -2 %/+3 % |
| ambient temperature | -40 |
| broad band noise to | EN 61373 |
| emc to standard ... | EN 61000-4-4 EN 61000-6-2 EN 61000-4-5 EN 61000-6-4 EN 61000-4-6 EN 61000-4-2 EN 61000-4-3 |
| etim reference group | EG000024 |
| overvoltage category | OV2 |
| power consumption dc | 7 |
| supply voltage 2 (v) | 24 |
| housing material code | PA |
| name of coding element | B |
| acc. shock to standard1 | 2g |
| acc. shock to standard2 | 5g |
| colour of coding element | gelb |
| eclass reference feature | 27242611 |
| protection type standard | EN 60529 |
| protection type, housing | IP20 |
| protection type, mounting | IP51 |
| type of supply voltage u1 | DC |
| type of supply voltage u2 | DC |
| uint1 short circuit proof | ja |
| vibration to standard ... | EN 50125-3 |
| perm. operating height asl | 2000 m |
| pot. isolation uint1 to u2 | 3050 V |
| ambient temp. to standard 2 | -40 ... +70 °C |
| ambient temp. to standard 3 | -40 ... +70 °C |
| app. site standard1 railway | EN 50125-3 |
| app. site standard2 railway | EN 61373 |
| climatic suitability to ... | EN 60068-2-30 EN 60068-2-2 EN 60068-2-1 EN 60068-2-78 EN 50155 EN 60068-2-14 |
| freq. broadband noise, rail | 5 ... 150 Hz |
| accel. broadband noise, rail | 0,79 g RMS |
| ambient temperature standard | EN 50155 |
| housing material front plate | PC |
| potential isolation u1 to u2 | 3050 V |
| standard 2 for ambient temp. | EN 50125-1 |
| standard 3 for ambient temp. | EN 50125-3 |
| standard1 b/band noise, rail | EN 61373 |
| clearance & creepage dist. to | EN 50124-1 |
| weee classifikation (08/2018) | 5 devices (feed size < 50cm) |
| app. site to standard1 railway | Gleisbereich (1m - 3m) |
| app. site to standard2 railway | Kategorie 1, Klasse A + B |
| bridge u-interrupt uint1 stan. | EN 61131-2 EN 61496-1 DIN V EN V 1954 |
| housing material lower section | PC |
| max. curr. contin. oper. uint1 | 1 |
| pollution degree clear.&creep. | PD2 |
