| Weight | 0.093 KG / psc. |
| Commodity number | 85389091 |
| Country of origin | DE |
| Dimensions (WxHxD) | 25.2x76x60.2 mm |
| EAN code | |
| Product group | 7017 |
| approval | CE UKCA EAC (Eurasian) TÜV |
| etim version | ETIM-7.0 |
| gross weight | 100 |
| eclass version | ECLASS-9.1 |
| terminal style | steckbar |
| permitted loads | ohmsch induktiv |
| reach compliance | contains min. 1 SVHC-substance |
| application range | Fail-safe |
| ambient temperature | -40 |
| broad band noise to | EN 61373 |
| emc to standard ... | EN 61000-6-2 EN 61000-4-4 EN 61000-4-5 EN 61000-6-4 EN 61000-4-6 EN 61000-4-2 EN 61000-4-3 |
| etim reference group | EG000024 |
| overvoltage category | OV2 |
| housing material code | PA |
| name of coding element | H |
| pot.isol. rlcont to u2 | 4900 V (sich. Trennung) |
| relay contact material | AgCuNi |
| acc. shock to standard1 | 2g |
| acc. shock to standard2 | 5g |
| condensation permitted? | bei Schutzkleinsp.: kurzzeitig |
| number of relay outputs | 2 |
| colour of coding element | gelb |
| eclass reference feature | 27242604 |
| pot.isol. rlcont - uint1 | 4900 V (sich. Trennung) |
| protection type standard | EN 60529 |
| protection type, housing | IP20 |
| voltage ac1 safety cont. | 250 |
| voltage dc1 safety cont. | 24 |
| protection type, mounting | IP51 |
| vibration to standard ... | EN 50125-3 |
| voltage ac15 safety cont. | 230 |
| voltage dc13 safety cont. | 24 |
| perm. operating height asl | 2000 m |
| pot.isol. rlcont1 to crail | 3050 V (Basisisolierung) |
| ambient temp. to standard 2 | -40 ... +70 °C |
| ambient temp. to standard 3 | -40 ... +70 °C |
| app. site standard1 railway | EN 50125-3 |
| app. site standard2 railway | EN 61373 |
| climatic suitability to ... | EN 50125-1 EN 60068-2-2 EN 60068-2-1 EN 50155 EN 60068-2-14 EN 50125-3 |
| freq. broadband noise, rail | 5 ... 150 Hz |
| accel. broadband noise, rail | 0,79 g RMS |
| addit. contact details relay | + 0,2 µm Au |
| ambient temperature standard | EN 50155 |
| housing material front plate | PC |
| pot.isol. rlcont1 to rlcont2 | 4900 V (sich. Trennung) |
| standard 2 for ambient temp. | EN 50125-1 |
| standard 3 for ambient temp. | EN 50125-3 |
| standard1 b/band noise, rail | EN 61373 |
| storage temperature standard | EN 60068-2-1/-2 |
| clearance & creepage dist. to | EN 50124-1 |
| max. current ac1 safety cont. | 8 |
| max. current dc1 safety cont. | 8 |
| weee classifikation (08/2018) | 5 devices (feed size < 50cm) |
| app. site to standard1 railway | Gleisbereich (1m - 3m) |
| app. site to standard2 railway | Kategorie 1, Klasse A + B |
| housing material lower section | PC |
| max. current ac15 safety cont. | 3 |
| pollution degree clear.&creep. | PD2 |
| typ. process time relay o/p on | 20 - 60 ms |
| utilisation cat. ac/dc1 stand. | EN 60947-4-1 |
| utilisation cat. ac15/dc13sta. | EN 60947-5-1 |
