| Weight | 0.093 KG / psc. |
| Commodity number | 85389091 |
| Country of origin | DE |
| Dimensions (WxHxD) | 25x110.8x72.5 mm |
| EAN code | |
| Product group | 7088 |
| approval | CE UKCA cULus Listed KOSHA TÜV EAC (Eurasian) |
| etim version | ETIM-7.0 |
| gross weight | 110 |
| eclass version | ECLASS-9.1 |
| terminal style | steckbar |
| humidity rating | 93 % r. F. bei 40 °C |
| permitted loads | ohmsch induktiv |
| housing material | PC |
| reach compliance | contains min. 1 SVHC-substance |
| application range | Fail-safe |
| ambient temperature | 0 |
| emc to standard ... | P_EMV_NORM_EN 61131-2 (Zone B) |
| etim reference group | EG000024 |
| overvoltage category | II |
| overvoltage category 2 | III |
| potential isolation u2 | ja |
| relay contact material | AgCuNi |
| acc. shock to standard1 | 150 m/s² |
| condensation permitted? | unzulässig |
| number of relay outputs | 2 |
| eclass reference feature | 27242604 |
| protection type standard | EN 60529 |
| protection type, housing | IP20 |
| voltage ac1 safety cont. | 250 |
| voltage dc1 safety cont. | 24 |
| protection type, mounting | IP54 |
| safety contacts: ac at ul | 250 V AC G.U. (same polarity) |
| vibration to standard ... | EN 60068-2-6 |
| voltage ac15 safety cont. | 230 |
| voltage dc13 safety cont. | 24 |
| perm. operating height asl | 2000 m |
| climatic suitability to ... | EN 60068-2-30 EN 60068-2-2 EN 60068-2-1 EN 60068-2-78 EN 60068-2-14 |
| safety contacts: pilot duty | B300, R300 |
| addit. contact details relay | + 0,2 µm Au |
| ambient temperature standard | EN 60068-2-14 |
| pot. isolation relay outputs | ja |
| storage temperature standard | EN 60068-2-1/-2 |
| clearance & creepage dist. to | EN 61131-2 UL/IEC 61010-2-201 |
| climatic suitability standard | EN 60068-2-78 |
| max. current ac1 safety cont. | 10 |
| max. current dc1 safety cont. | 10 |
| potential isolation 1 between | P_POT_TRENN_1_RL-Ausgang und RL-Ausgang |
| potential isolation 2 between | P_POT_TRENN_2_RL-Ausgang u. Periphery Supply |
| potential isolation 3 between | P_POT_TRENN_3_RL-Ausgang und Module Supply |
| potential isolation 4 between | P_POT_TRENN_4_Periphery und Module Supply |
| type of potential isolation 1 | sichere Trennung |
| type of potential isolation 2 | sichere Trennung |
| type of potential isolation 3 | sichere Trennung |
| type of potential isolation 4 | Funktionisolierung |
| weee classifikation (08/2018) | 5 devices (feed size < 50cm) |
| clearance & creepage dist.to 2 | EN 60664-1 |
| max. current ac15 safety cont. | 3 |
| pollution degree clear.&creep. | 2 |
| utilisation cat. ac/dc1 stand. | P_SCHALTVERMOEGEN_NACH_EN 60947-4-1 |
| utilisation cat. ac15/dc13sta. | EN 60947-5-1 |
