Pilz

380321

Name: 380321
Brand: Pilz
Availability: PreOrder

Product type: PSS67 Supply cable 5x0.5

Datasheet

Description

By the metre, PUR, black RAL9005, 5x0.5, suitable for drag chains,colour of the single wires: Brown, white, blue, black, grey

Payment

Worldwide shipping

Additional Information
Price: Please send request
Request Lead Time: ca. 1-2 Days
Delivery Time: By Agreement
Delivery Terms: FCA Berlin individually for each client according to INCOM TERMS 2022

ZWOD Vertriebs und Logistik GmbH specializes in hard-to-find parts. Please send request a quote and save on 380321.
ZWOD Vertriebs und Logistik GmbH carries 3973 items from Pilz.

Multiples Of: 1

Product Specifications

Product Attribute	Attribute Value
Weight	0.05 KG / psc.
Commodity number	85444995
Country of origin	DE
Dimensions (WxHxD)
EAN code
Product group	7169
approval	CE UKCA
etim version	ETIM-7.0
gross weight	50 g
halogen-free	yes
shielding k1	no
stranding k1	5 cores round PP splice yarn
cable type k1	Li9YH-11YH
eclass version	ECLASS-9.1
oil resistance	resistant
flame resistance	UL 1581 CSA 22.2 FT2
cable material k1	Cu
ambient temperature	-25 - 80 °C
number of conductors	5
approvals for cable k1	UL AWM-Style 20549
conductor cross section	0.5 mm²
eclass reference feature	27060411
colour cable insulation 1	Black, similar to RAL9005
cable cross section awg k1	20
bend radius (when laying) k1	5 x Ø
insulation material cable k1	PP9P
typ. conductor resistance k1	39 Ohm/km
weee classifikation (08/2018)	0 not relevant
insulation resistance cable k1	1000 MOhm x km
material of cable insulation 1	TPU / TPE-U PUR
max. outside diameter cable k1	6.2 mm
specific conductor capacity k1	105pF/m
specific contact resistance k1	>= 1E+17 Ohm*cm
trailing capability of cable 1	yes
