Pilz

630810

Name: 630810
Brand: Pilz
Availability: PreOrder

Product type: PSEN op4B-T-050/1

Datasheet

Description

Set from light guard (Type 4, PL e, body protection), bracket and mutingarm T-type in accordance with DIN EN 61496, Type 4, 500 mm, connector M12,transmitter: 4-pin and 5-pin, receiver: 5-pin and 8-pin, connection cable not supplied with the device.

Sensor technology
Optoelectronic protective devices
PSENopt - Safety light curtains
Basic Type 4 light curtain, body protection

Contact Person
Thomas Hoffmann
+49 305 201 4443 ext. 1
sales@zwodltd.com

Payment

Worldwide shipping

Additional Information
Price: Please send request
Request Lead Time: ca. 1-2 Days
Delivery Time: By Agreement
Delivery Terms: FCA Berlin individually for each client according to INCOM TERMS 2022

ZWOD Vertriebs und Logistik GmbH specializes in hard-to-find parts. Please send request a quote and save on 630810.
ZWOD Vertriebs und Logistik GmbH carries 3973 items from Pilz.

Multiples Of: 1

Product Specifications

Product Attribute	Attribute Value
Weight	5.6 KG / psc.
Commodity number	90314990
Country of origin	HU
Dimensions (WxHxD)	35x653x41.2 mm
EAN code
Product group	7040
approval	CE cULus Listed TÜV
espe type	4
etim version	ETIM-7.0
gross weight	6100
reaction time	14 14
eclass version	ECLASS-9.1
humidity rating	95 % r. h. at 50 °C
sensor principle	optical
supply voltage (v)	24 24
ambient temperature	-10 55
operating range (m)	0.5 3
etim reference group	EG000026
used wavelength range	880 nm
number of ossd outputs	2
acc. shock to standard1	10g
condensation permitted?	Not permitted
eclass reference feature	27272703
protection type standard	EN 60529
height of protected field	515
type of supply voltage u1	DC
vibration to standard ...	EN 60068-2-6
resolution protection type	Body
housing material upper part	Aluminium
weee classifikation (08/2018)	4 devices (feed size >50 cm)
pollution degree clear.&creep.	2
