Pilz

631070

Name: 631070
Brand: Pilz
Availability: PreOrder

Product type: PSEN op Advanced Programming Adapter

Datasheet

Description

Programming adapter for the PSEN opXX-A series. Using the PC Software all the functions (muting, blanking, cascading) of the light guards of the Advanced series can be set. The dongle can also be used to save configurations in the light guard and to transfer it to other light guards. 3x M12 connector adapter: 12- pin, muting: 5-pin, connection configuration: 4-pin Ethernet. Connection cables are not supplied with the device.

Sensor technology
Optoelectronic protective devices
PSENopt - Safety light curtains
Accessories PSENopt

Contact Person
Thomas Hoffmann
+49 305 201 4443 ext. 1
sales@zwodltd.com

Payment

Worldwide shipping

Additional Information
Price: Please send request
Request Lead Time: ca. 1-2 Days
Delivery Time: By Agreement
Delivery Terms: FCA Berlin individually for each client according to INCOM TERMS 2022

ZWOD Vertriebs und Logistik GmbH specializes in hard-to-find parts. Please send request a quote and save on 631070.
ZWOD Vertriebs und Logistik GmbH carries 3973 items from Pilz.

Multiples Of: 1

Product Specifications

Product Attribute	Attribute Value
Weight	0.093 KG / psc.
Commodity number	90319000
Country of origin	IT
Dimensions (WxHxD)	35x40.7x130.9 mm
EAN code
Product group	7040
approval	C-TICK CE
etim version	ETIM-7.0
gross weight	157 g
eclass version	ECLASS-9.1
humidity rating	95 % r. h. at 50 °C
connector type 1	12-pin M12 male connector
connector type 2	5-pin M12 male connector
connector type 3	4-pin M12 ETH female connector
housing material	NANYA PBT 1400 G3
supply voltage (v)	24 V
ambient temperature	0 - 55 °C
acc. shock to standard1	10g
condensation permitted?	Not permitted
eclass reference feature	27272791
protection type standard	EN 60529
type of supply voltage u1	DC
vibration to standard ...	EN 60068-2-6
weee classifikation (08/2018)	5 devices (feed size < 50cm)
