| Weight | 0.4 KG / psc. |
| Commodity number | 85364900 |
| Country of origin | DE |
| Dimensions (WxHxD) | 45x100x120 mm |
| EAN code | |
| Product group | 7003 |
| approval | CCC CE cULus Listed EAC (Eurasian) TÜV |
| etim version | ETIM-7.0 |
| gross weight | 420 g |
| eclass version | ECLASS-9.1 |
| terminal style | plug-in |
| humidity rating | 93 % r. h. at 40 °C |
| tolerance of u2 | -15 %/+10 % |
| reach compliance | contains min. 1 SVHC-substance |
| mounting position | horizontal on top hat rail |
| supply voltage (v) | 24 - 240 V |
| ambient temperature | -20 - 55 °C |
| connection terminal | Spring-loaded terminal |
| emc to standard ... | EN 60947-5-1 EN 61000-6-2 EN 61000-6-3 EN 61326-3-1 |
| etim reference group | EG000019 |
| overvoltage category | II |
| power consumption ac | 9 VA |
| power consumption dc | 5.5 W |
| semiconductor inputs | 4 |
| supply voltage 2 (v) | 48 - 240 V |
| relay contact material | AgCuNi |
| condensation permitted? | Not permitted |
| eclass reference feature | 27371811 |
| type of analogue outputs | Current |
| voltage ac1 safety cont. | 240 V |
| voltage dc1 safety cont. | 24 V |
| safety contacts: ac at ul | 240 VAC G.U. (same polarity) |
| type of supply voltage u1 | AC/DC |
| type of supply voltage u2 | AC |
| vibration to standard ... | EN 60068-2-6 |
| voltage ac15 safety cont. | 230 V |
| voltage dc13 safety cont. | 24 V |
| number of analogue outputs | 1 |
| signal range analog output | 4 .. 20 mA 0 .. 20 mA |
| climatic suitability to ... | EN 60068-2-78 |
| housing material upper part | PC |
| max. device circuit breaker | Max. conductor cross section |
| number of semicond. outputs | 4 |
| tolerance ext. volt. dc s/c | -20 %/+20 % |
| addit. contact details relay | + 0.2 µm Au |
| housing material front plate | PC |
| clearance & creepage dist. to | EN 60947-1 |
| max. current ac1 safety cont. | 4 A |
| max. current dc1 safety cont. | 4 A |
| number of incremental encoder | 1 |
| weee classifikation (08/2018) | 5 devices (feed size < 50cm) |
| connection (increment encoder) | 8-pin RJ-45 female connector |
| housing material lower section | PC |
| max. current ac15 safety cont. | 3 A |
| phase pos. diff.sign. inc.enc. | 90° ±30° |
| pollution degree clear.&creep. | 2 |
| prog. mon. fun. wo hyst. incr. | 10 mHz - 1,000 kHz |
| prog. mon.fun. wo hyst prox sw | 10 mHz - 1,000 kHz |
| reaction time over limit value | 1/f_actual + 16ms |
| utilisation cat. ac/dc1 stand. | EN 60947-4-1 |
| utilisation cat. ac15/dc13sta. | EN 60947-5-1 |
| utilisation cat. to en 60947-1 | DC-12 |
