| Weight | 0.19 KG / psc. |
| Commodity number | 85389091 |
| Country of origin | DE |
| Dimensions (WxHxD) | 22.5x101.4x120 mm |
| EAN code | |
| Product group | 7108 |
| cas no. | 1317-36-8 |
| approval | CE UKCA cULus Listed KOSHA TÜV EAC (Eurasian) |
| etim version | ETIM-7.0 |
| gross weight | 205 g |
| eclass version | ECLASS-9.1 |
| rohs directive | 2011/65/EU 2015/863/EU |
| terminal style | plug-in |
| permitted loads | Resistive Inductive |
| rohs conformity | yes |
| rohs exceptions | yes |
| purpose of uint1 | Module supply |
| reach compliance | contains min. 1 SVHC-substance |
| application range | Failsafe |
| mounting position | horizontal on top hat rail |
| ambient temperature | 0 - 60 °C |
| connection terminal | Screw terminal Spring-loaded terminal |
| din-rail dimensions | 35 x 7.5 EN 50022 |
| emc to standard ... | EN 61131-2 |
| etim reference group | EG000024 |
| overvoltage category | II |
| pilot duty r300 to ul | 24 V DC |
| voltage type of uint1 | DC |
| relay contact material | AgCuNi |
| %-part of the pollutant | > 0,1 |
| acc. shock to standard1 | 15g |
| condensation permitted? | Not permitted |
| number of relay outputs | 4 |
| eclass reference feature | 27242204 |
| flex. cond. c/s awg info | 24 - 12 AWG |
| number of digital inputs | 4 |
| protection type standard | EN 60529 |
| voltage ac1 safety cont. | 250 V |
| voltage dc1 safety cont. | 24 V |
| potential isolation input | No |
| reach included substances | Lead oxide |
| safety contacts: ac at ul | 240 VAC G.U. Resistive |
| vibration to standard ... | EN 60068-2-6 |
| voltage ac15 safety cont. | 230 V |
| voltage dc13 safety cont. | 24 V |
| perm. operating height asl | 2000 m |
| source of internal voltage | Via base unit |
| housing material upper part | PC |
| addit. contact details relay | + 0.2 µm Au |
| ambient temperature standard | EN 60068-2-14 |
| housing material front plate | PC |
| pot. isolation relay outputs | Yes |
| storage temperature standard | EN 60068-2-1/-2 |
| u input to en 61131-2 type 1 | 24 V DC |
| clearance & creepage dist. to | EN 61131-2 |
| climatic suitability standard | EN 60068-2-30 EN 60068-2-78 |
| max. current ac1 safety cont. | 6 A |
| max. current dc1 safety cont. | 6 A |
| potential isolation 1 between | RL output and system voltage |
| rohs except.s acc. to direct. | 7c I |
| type of potential isolation 1 | Safe separation |
| weee classifikation (08/2018) | 5 devices (feed size < 50cm) |
| housing material lower section | PC |
| max. current ac15 safety cont. | 3 A |
| pollution degree clear.&creep. | 2 |
| utilisation cat. ac/dc1 stand. | EN 60947-4-1 |
| utilisation cat. ac15/dc13sta. | EN 60947-5-1 |
