| Weight | 0.108 KG / psc. |
| Commodity number | |
| Country of origin | |
| Dimensions (WxHxD) | 22.5x101.4x120 mm |
| EAN code | |
| Product group | 7108 |
| approval | CE UKCA cULus Listed KOSHA TÜV EAC (Eurasian) |
| etim version | ETIM-7.0 |
| gross weight | 117 g |
| purpose of u2 | Supply sensor evaluation |
| eclass version | ECLASS-9.1 |
| terminal style | plug-in |
| purpose of uint1 | Module supply |
| application range | Failsafe |
| mounting position | horizontal on top hat rail |
| ambient temperature | 0 - 60 °C |
| connection terminal | Spring-loaded terminal Screw terminal |
| din-rail dimensions | 35 x 7.5 EN 50022 |
| emc to standard ... | EN 61131-2 |
| etim reference group | EG000024 |
| overvoltage category | II |
| supply voltage 2 (v) | 24 V |
| type of input filter | RC filter 1st order |
| voltage type of uint1 | DC |
| potential isolation u2 | Yes |
| acc. shock to standard1 | 15g |
| condensation permitted? | Not permitted |
| type of analogue inputs | Current |
| eclass reference feature | 27242201 |
| flex. cond. c/s awg info | 24 - 12 AWG |
| protection type standard | EN 60529 |
| number of analogue inputs | 4 |
| type of supply voltage u2 | DC |
| vibration to standard ... | EN 60068-2-6 |
| analog input signal type 2 | Differential input |
| analog input signal type 3 | Differential input |
| analogue input data format | Float |
| perm. operating height asl | 2000 m |
| source of internal voltage | Via base unit |
| analog input signal range 2 | 4.. 20 mA |
| analog input signal range 3 | 0 .. 25 mA |
| housing material upper part | PC |
| ambient temperature standard | EN 60068-2-14 |
| conversion method analog i/p | Successive approximation |
| housing material front plate | PC |
| monotony without error codes | yes |
| res. anal. i/p i-measurement | 16 Bit (15 Bit + Vorzeichen) |
| storage temperature standard | EN 60068-2-1/-2 |
| clearance & creepage dist. to | EN 61131-2 |
| climatic suitability standard | EN 60068-2-30 EN 60068-2-78 |
| potential isolation 1 between | Sensor and system voltage |
| r analog current i/p+thresh.v | 156 Ohm + ca. 1.6V threshold V |
| type of potential isolation 1 | Functional insulation |
| weee classifikation (08/2018) | 5 devices (feed size < 50cm) |
| housing material lower section | PC |
| pollution degree clear.&creep. | 2 |
| potential isol. analogue input | Yes |
