| Weight | 0.136 KG / psc. |
| Commodity number | 85444290 |
| Country of origin | DE |
| Dimensions (WxHxD) | 31x24.8x85.2 mm |
| EAN code | |
| Product group | 7013 |
| cas no. | 7439-92-1 |
| approval | - |
| etim version | ETIM-7.0 |
| gross weight | 146 g |
| length cable | 0.2 m |
| shielding k1 | yes |
| shielding k2 | Yes |
| eclass version | ECLASS-9.1 |
| housing colour | Black RAL 9005 |
| rohs directive | 2011/65/EU 2015/863/EU |
| rohs conformity | yes |
| rohs exceptions | yes |
| connector type 1 | 10-pin RJ45 female connector |
| connector type 2 | 10-pin RJ45 male connector |
| connector type 3 | 8-pin RJ45 male connector |
| housing material | TPE-SEBS UL 94 HB |
| reach compliance | contains min. 1 SVHC-substance |
| cable material k1 | Cu |
| cable material k2 | Cu |
| ambient temperature | 0 - 60 °C |
| category of cable k1 | Cat5 |
| etim reference group | EG000026 |
| number of conductors | 10 |
| approvals for cable k1 | UL AWM-Style 20963 |
| approvals for cable k2 | UL AWM-Style 20233 |
| %-part of the pollutant | > 0,1 |
| condensation permitted? | Not permitted |
| conductor cross section | 0.14 mm² |
| eclass reference feature | 27060313 |
| approvals for connector 1 | UL94 V-0 |
| approvals for connector 2 | UL94 V-0 |
| approvals for connector 3 | UL94 V-0 |
| colour cable insulation 1 | Green |
| colour cable insulation 2 | Green |
| cross section ub cable k1 | 2 x 0.25 mm² |
| diameter data line awg k1 | 26 |
| reach included substances | Lead |
| shape of connector type 1 | straight |
| shape of connector type 2 | straight |
| shape of connector type 3 | straight |
| contact surfaces material 1 | Au |
| contact surfaces material 2 | Au |
| contact surfaces material 3 | Au |
| cross section data cable k1 | (4 x 2 x 0.14) mm² |
| bend radius (when laying) k1 | 10 x Ø |
| bend radius (when laying) k2 | 8 x Ø |
| housing material connector 3 | PBT |
| tolerance of cable length k1 | + 0.055m |
| tolerance of cable length k2 | +/- 0.15 m |
| rohs except.s acc. to direct. | 6c |
| separating layer bt. cores k2 | No |
| weee classifikation (08/2018) | 5 devices (feed size < 50cm) |
| bend radius constant motion k2 | 10 x Ø |
| material of cable insulation 1 | PUR |
| material of cable insulation 2 | PUR |
| max. outside diameter cable k1 | 7 mm |
| trailing capability of cable 1 | yes |
| trailing capability of cable 2 | Yes |
