| Weight | 0.5 KG / psc. |
| Commodity number | 85044082 |
| Country of origin | China |
| Dimensions (WxHxD) | 32x124x117 mm |
| EAN code | 875404001065 |
| Product group | A-Standard |
| Derating | 3W/°C for >+60°C |
| m_features | AC 100-120 / 200-240V auto-select input; Width only 32mm; Quick-connect spring-clamp terminals; Efficiency up to 90.2%; Easy fuse breaking due to high overload peak current; 20% Output power reserves; Full power between -25°C and +60°C; Minimal inrush current surge |
| Output power | 120W |
| Power factor | 0.47 |
| Output current | 4.3A at 28V; 5A at 24V |
| Packaging unit | 1 pc |
| Power reserves | 20% Power Boost |
| Product status | Lead time on request |
| Mounting method | DIN rail |
| Nominal voltage | 24Vdc |
| AC Input voltage | AC 100 - 120 / 200 - 240V (± 10%) |
| Adjustment range | 24 - 28V |
| E classification | eClass 5.1 27049002; eClass 6.x 27049002; eClass 7.x 27049002; eClass 8.0 27049002; eClass 9.0 27040701; ETIM 4.0 EC000599; ETIM 5.0 EC002540 |
| Efficiency, typ. | 90.2% |
| Connection method | Spring clamps |
| Power losses, typ. | 13.2W |
| Input inrush current | 3A / 3A |
| Output current range | 5 - 4.3A |
| Operating temp. range | -25°C to 70°C |
| Warranty period (months) | 36 |
| MTBF SN 29500 @ 40°C (h) | 869000h |
| Ripple and noise voltage max. | 50mVpp |
| Input inrush current limitation | active |
| Weight per unit (excl. packaging) | 500g |
| External input fuse recommendation | B-10A / C-6A |
