| Weight | 0.24 KG / psc. |
| Commodity number | 85044082 |
| Country of origin | China |
| Dimensions (WxHxD) | 45x75x98 mm |
| EAN code | 875404000112 |
| Product group | A-Standard |
| Derating | 1.3W/°C for >+60°C |
| m_features | 100-240V wide-range input; DC-OK signal output; Parallel mode for load sharing; NEC Class 2 listed; Full output power between -10 and +60°C; Plug connector with screw terminations adapter for wall mounting included |
| DC-OK signal | yes |
| Output power | 50W |
| Power factor | 0.56/ 0.52 |
| Output current | 1.8A at 28V; 2.1A at 24V |
| Packaging unit | 1 pc |
| Product status | Lead time on request |
| Mounting method | DIN rail |
| Nominal voltage | 24Vdc |
| AC Input voltage | AC 100 - 240V |
| Adjustment range | 24 - 28V |
| DC Input voltage | DC 110V - 300V (-20%/+25%) |
| E classification | eClass 5.1 27049002; eClass 6.x 27049002; eClass 7.x 27049002; eClass 8.0 27049002; eClass 9.0 27040701; ETIM 4.0 EC000599; ETIM 5.0 EC002540 |
| Efficiency, typ. | 88.4% |
| Connection method | Plug connector |
| Input inrush current | 17A / 35A |
| Output current range | 2.1 - 1.8A |
| Warranty period (months) | 36 |
| MTBF SN 29500 @ 40°C (h) | 2613000h |
| Ripple and noise voltage max. | 50mVpp |
| Input inrush current limitation | NTC |
| Weight per unit (excl. packaging) | 240g |
| External input fuse recommendation | B-10A / C-6A |
