| Weight | 0.12 KG / psc. |
| Commodity number | 85363010 |
| Country of origin | China |
| Dimensions (WxHxD) | 45x75x91 mm |
| EAN code | 875404001805 |
| Product group | D-non-standard |
| m_features | One input and four current controlled outputs; Ensures sufficient supply voltage for critical loads even in the event of a fault; Protects small cable sizes against overload; Hassle-free turn-on of loads with large input capacitors; Wide temperature range between -25°C and +70°C; On/Off function of outputs; Compact design, width only 45mm; Remote monitoring and control function |
| Output current | 6A 6A 6A 6A |
| Packaging unit | 1 pc |
| Product status | Lead time on request |
| Mounting method | DIN rail |
| Adjustment range | 24 - 28V |
| DC Input voltage | DC 18V - 30V |
| E classification | eClass 5.1 27141116; eClass 6.x 27141116; eClass 7.x 27141116; eClass 8.0 27141116; eClass 9.0 27141116; ETIM 4.0 EC000899; ETIM 5.0 EC000899 |
| Connection method | Screw terminals |
| Power losses, typ. | 2.4W |
| No-load losses, typ. | 1.0W |
| Operating temp. range | -25°C to 70°C |
| Turn-on delay of outputs | 270ms |
| Warranty period (months) | 36 |
| MTBF SN 29500 @ 40°C (h) | 1942000h |
| DC Input current at no load, typ. | 43mA |
| Weight per unit (excl. packaging) | 120g |
| Output current (sum of all outputs) | 20A |
| Output current limitation min./max. | 20.5 / 30A |
| Shutdown-times at short circuit, typ. | 8ms |
| Input voltage protection level min./max. | 21 - 21.8Vdc |
| Input voltage required to switch on the outputs, typ. | 21.4Vdc |
